ams Datasheet

Page 31

[v1-04] 2018-Jul-09

Document Feedback

AS7265x − Detailed Description

Detailed Register Descriptions

Figure 27:

HW Version Registers

Figure 28:

FW Version Registers

Figure 29:

Configuration Register

Addr: 0x00,0x01

HW Version

Bit

Bit Name

Default

Access

Bit Description

15:8

HW version H

0x40

Device type

7:0

HW version L

0x41

HW version

Addr: 0x02,0x03

FW Version

Bit

Bit Name

Default

Access

Bit Description

15:8

FW version H

R/W

Set register 0x02, 0x03 to 0x01 to 0x03 to get

each firmware positions high byte

0x01: MAJOR version [15..8]

0x02: PATCH version [15..8]

0x03: BUILD version [15..8]

7:0

FW version L

R/W

Addr: 0x04

Configuration

Bit

Bit Name

Default

Access

Bit Description

7:0

SRST

[W] software reset [R] gain error

6INT

R/W

Enable interrupt pin

5:4

GAIN

R/W

Gain configuration: b00=1x; b01=3.7x; b10=16x;

b11=64x

3:2

BANK

R/W

Measurement mode:

b00=Mode 0: 4 channels

b01=Mode 1: 4 channels

b10=Mode 2: All 6 channels

b11=Mode 3: One-Shot operation of mode 2

DATA_RDY

Data ready to read

0FRST

Factory reset
