KW-CSLPM2-PC Datasheet(PDF) 2 Page - ams-OSRAM AG |
|
|
|||||||||||||||||||||||||||||
KW-CSLPM2-PC Datasheet(HTML) 2 Page - ams-OSRAM AG |
|
|
2 / 25 page  KW CSLPM2.PC DATASHEET DATASHEET 2 | Version 1.7 | 2023-01-04 OSLON® Square Flat KW CSLPM2.PC The most compact 3 x 3 mm high power LED with an electrical- ly isolated thermal pad allows for superior heat dissipation de- signs. The flat package shape enhances color homogeneity due to reduced color over angle variation. Extremely low thermal resistance helps to maintain the efficiency remarkably high even when driven at higher currents. Applications - Entertainment - Transportation Features - Package: Ceramic package - Chip technology: UX:3 - Typ. Radiation: 120° (Lambertian emitter) - Color: Cx = 0.32, Cy = 0.33 acc. to CIE 1931 (● white) - Corrosion Robustness Class: 2B - Color temperature: 5000K - 6500K - CRI: 70 (typ.) - ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B) |
|
|
