ND30PNET - METEROFPOWERNETWORKPARAMETERSWITHPROFINET

DISPLAYING OF MEASUREMENT PARAMETERS

two screens dedicated to harmonics;

indication of individual harmonic

for voltages and currents (up to 51st);

bargraph presentation for all harmonics

with zoom function

easy to use and intuitive menu;

information bar with status of: phase

sequence, alarm outputs, temperature

measurements, binary inputs*

and RS-485 interfaces,

time and date

*- availability of feature depends on

hardware version of ND30PNET

up to 10 programmable screens

(8 parameters per page);

ability to change color for all screens

Available colors for digital indications:

presentation in the form of analog

meter view with min/max preview

for display value and zoom function
