2 / 23 page  KW EELP41.RU DATASHEET DATASHEET 2 | Version 1.2 | 2025-07-10 SMARTLED™ 0603 KW EELP41.RU The SMARTLED™ 0603 is the product of choice for status indi- cation and symbol backlighting in electronics. The small package size allows compact designs. The improved corrosion robustness and increased junction temperature range makes the devices from this series suitable for professional industrial equipment and applications. Applications - Appliances & Tools - Display Backlighting - Factory Automation - Home & Building Automation - Projection & Display - Static Signaling - Transportation Features - Package: SMT package 0603, colored diffused resin - Chip technology: Volume emitter on Sapphire (AlInGaN) - Typ. Radiation: 130° (horizontal = 0°), 150° (vertical = 90°) - Color: Cx = 0.3, Cy = 0.29 acc. to CIE 1931 (● white) - Corrosion Robustness Class: 3B - ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B) |
|
|
