background image
MCIB-HDMI/HDMI
Specification
Version: 1
Date: 16/04/2018
Revision
Electra House, 32 Southtown Road
Great Yarmouth, Norfolk
NR31 0DU, England
Telephone +44 (0)1493 602602
Fax +44 (0)1493 665111
Email:sales@midasdisplays.com
www.midasdisplays.com
Compatible Displays
MCT050HDMI-A-RTP
MCT050HDMI-A-CTP
MCT070HDMI-B-RTP
MCT070HDMI-B-CTP
MCT101HDMI-A-RTP
MCT101HDMI-A-CTP
Interconnect Board
16/04/2018 First Release.
1
5" HDMI TFT. Resistive and
Capacitive touch, respectively.
7" HDMI TFT. Resistive and
Capacitive touch, respectively.
10.1" HDMI TFT. Resistive and
Capacitive touch, respectively.
Interconnect Board Description
A
Male HDMI Connector
A
A
Midas Components Ltd
MCIB-HDMI/HDMI
1
1.5:1
Allow for +/- 2-3mm
for all dimensions.
