Data Sheet

ADRF5716

SPECIFICATIONS

analog.com

Rev. 0 | 4 of 15

Table 1. Specifications (Continued)

Parameter

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

DIGITAL CONTROL INPUTS

LE, D5, and D6

Voltage

Low

VINL

0

0.8

V

High

VINH

1.2

3.3

V

Current

Low

IINL

−33

µA

High

IINH

<1

µA

SUPPLY CURRENT

VDD and VSS

Positive Supply Current

LE, D5, and D6 = 0 V

230

µA

LE, D5, and D6 = 3.3 V2

130

µA

Negative Supply Current

500

µA

RECOMMENDED OPERATING CONDITIONS

Supply Voltage

Positive

VDD

3.15

3.45

V

Negative

VSS

−3.45

−3.15

V

Digital Control Voltage

0

VDD

V

RF Power Handling3

f = 100 MHz to 30 GHz, TCASE = 85°C4

Input at ATTIN or ATTOUT

Steady state average

30

dBm

Steady state peak

33

dBm

Hot switching

30

dBm

Case Temperature

TCASE

−40

+105

°C

1 Input linearity performance degrades over frequency, see Figure 16 to Figure 19.

2 If LE, D5, and D6 are in a different combination of states, the positive supply current is between 130 μA and 230 μA.

3 For power derating over frequency, see Figure 2 and Figure 3. Applicable for all ATTIN and ATTOUT power specifications.

4 For 105°C operation, the power handling degrades from the TCASE = 85°C specifications by 3 dB.
