SMTHBT200 Datasheet(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
SMTHBT200 Datasheet(HTML) 1 Page - STMicroelectronics |
|
|
1 / 6 page  SMTHBT200 ® August 1999 - Ed : 3A TRISIL TM FOR LINE CARD PROTECTION BIDIRECTIONAL CROWBAR PROTECTION REPETITIVE PEAK PULSE CURRENT: IPP = 100 A (10/1000 µs) HOLDING CURRENT: IH = 150 mA BREAKDOWN VOLTAGE : 200V min BREAKOVER VOLTAGE : 265V max FEATURES This protection device has been especially designed to protect subscriber line cards using SLICS without integrate d ring gen erators. The SMTHBT200 device protects ring generat or relays against transient DESCRIPTION - CCITT K20: 10/700 µs4 kV 5/310 µs 100 A - VDE 0433: 10/700 µs4 kV 5/310 µs 100 A - VDE 0878: 1.2/50 µs4 kV 1/20 µs 100 A - FCC Part 68: 2/10 µs 2.5 kV BELLCORE TR-NWT-001089: 2/10 µs 500 A - BELLCORE TR-NWT-000974: 10/1000 µs1 kV 10/1000 µs 100 A INACCORDANCE WITH THEFOLLOWINGSTANDARDS : SCHEMATIC DIAGRAM SMC 1/6 |
