Electrical data

L6393

6/20

4

Electrical data

4.1

Absolute maximum ratings

Note:

ESD immunity for pins 12, 13 and 14 is guaranteed up to V (Human Body Model)

4.2

Thermal data

Table 4.

Absolute maximum rating

Symbol

Parameter

Value

Unit

Output voltage

V

Supply voltage

- 0.3 to + 21

V

Comparator negative input voltage

V

Comparator positive input voltage

V

Floating supply voltage

V

High side gate output voltage

output voltage

V

High side gate output voltage

output voltage

V

Logic input voltage

-0.3 to 15

V

Open drain voltage

-0.3 to 15

V

50

V/ns

TBD

mW

Junction temperature

150

°C

Storage temperature

-50 to 150

°C

Table 5.

Thermal data

Symbol

Parameter

SO-14

DIP-14

Unit

Thermal resistance junction to ambient max.

165

100

°C/W
