background image
3/11
STP45NF3LL - STB45NF3LL
ELECTRICAL CHARACTERISTICS (CONTINUED)
SWITCHING ON
SWITCHING OFF
SOURCE DRAIN DIODE
Note: 1. Pulsed: Pulse duration = 300 µs, duty cycle 1.5 %.
2. Pulse width limited by safe operating area.
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
td(on)
Turn-on Delay Time
VDD =15 V,ID = 22.5A
RG = 4.7Ω VGS =4.5V
(Resistive Load, see Fig. 3)
17
ns
tr
Rise Time
100
ns
Qg
Qgs
Qgd
Total Gate Charge
Gate-Source Charge
Gate-Drain Charge
VDD =24V, ID = 45A,
VGS =5V
12.5
4.6
5.2
17
nC
nC
nC
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
td(off)
tf
Turn-off-Delay Time
Fall Time
VDD = 15V, ID = 22.5A,
RG =4.7Ω, VGS = 4.5V
(Resistive Load, see Fig. 3)
20
21
ns
ns
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
ISD
Source-drain Current
45
A
ISDM (2)
Source-drain Current (pulsed)
180
A
VSD (1)
Forward On Voltage
ISD = 45A, VGS =0
1.3
V
trr
Qrr
IRRM
Reverse Recovery Time
Reverse Recovery Charge
Reverse Recovery Current
ISD = 45A, di/dt = 100A/µs,
VDD =15V, Tj = 150°C
(see test circuit, Figure 5)
35
44
2.5
ns
nC
A
Safe Operating Area for TO-220/D2PAK
Thermal Impedance for TO-220/D2PAK
