STPC12GDYI Datasheet(PDF) 41 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
STPC12GDYI Datasheet(HTML) 41 Page - STMicroelectronics |
|
|
41 / 111 page  STRAP OPTION Issue 1.0 - July 24, 2002 41/111 MD 45 CPUCLK/HCKL Deskew Programming Pull down HCLK between 64MHz and 133MHz MD 46 Pull up MD 47 Reserved2 Pull down - MD 48 Reserved2 Pull up - MD 50 Internal UART2 (see Section 3.1.4. ) Pull up Enable MD 51 Internal UART1 (see Section 3.1.4. ) Pull up Enable MD 52 Internal Kbd / Mouse (see Section 3.1.4. ) Pull up Enable MD 53 Internal Parallel Port (see Section 3.1.4. ) Pull up Enable TC1 Reserved2 Pull up - DACK_ENC[2]1 Reserved2 Pull up - DACK_ENC[1]1 Reserved2 Pull up - DACK_ENC[0]1 Reserved2 Pull up - Signal Designation Actual Settings Description Note1: Strap options on TC/PA[3] and DACK_ENC[2:0]/PA[2:0] are required for all the STPC Atlas Configurations (ISA, PCMCIA, Local Bus). Note2: Must be implemented. Table 3-1. Typical Strap Option Implementation |
|
