TDA7262
20+20W STEREO AMPLIFIER WITH STAND-BY
WIDE SUPPLY VOLTAGE RANGE
HIGH OUTPUT POWER
28+28W TYP. MUSIC POWER
20+20W @ THD = 10%, RL =4
Ω,VS = 28V
HIGH CURRENT CAPABILITY (UP TO 3.5A)
STAND-BY FUNCTION
AC SHORT CIRCUIT PROTECTION
THERMAL OVERLOAD PROTECTION
DESCRIPTION
The TDA7262 is class AB dual Hi-Fi Audio power
amplifier assembled in Multiwatt package, spe-
cilally designed for high quality stereo application
as Hi-Fi music centers and TV sets.
March 1995
Figure 1: Stereo Application Circuit with Stand-By
MULTIWA TT11
ORDERING NUMBER: TDA7262
1/8
