PACKAGE MECHANICAL DATA

SO8 (Plastic)

REF.

DIMENSIONS

Millimetres

Inches

Min.

Typ.

Max.

Min.

Typ.

Max.

A

1.75

0.069

a1

0.1

0.25 0.004

0.010

a2

1.65

0.065

b

0.35

0.48 0.014

0.019

b1

0.19

0.25 0.007

0.010

C

0.50

0.020

c1

45

°(typ)

D

4.8

5.0

0.189

0.197

E

5.8

6.2

0.228

0.244

e

1.27

0.050

e3

3.81

0.150

F

3.8

4.0

0.15

0.157

L

0.4

1.27 0.016

0.050

M

0.6

0.024

S8

° (max)

Packaging = Products supplied in antistatic tubes

or tape and reel.
