VIPER20BSP Datasheet(PDF) 2 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
VIPER20BSP Datasheet(HTML) 2 Page - STMicroelectronics |
|
|
2 / 17 page  ABSOLUTE MAXIMUM RATING Symb ol Parameter Value Uni t VDS Continuous Drain-Source Voltage (T j = 25 to 125 oC) -0. 3 to 400 V ID Maximum Current Int ernally Limited A VDD Supply Voltage 0 t o 15 V VOSC Voltage Range I nput 0 t o VDD V VCOMP Voltage Range I nput 0 to 5 V ICOMP Maximum Continuous Current ±2mA Vesd Elect rostatic discharge (R = 1. 5 K Ω C = 100pF) 2000 V ID(AR) Avalanche Drain-Source Current , Repetitive or Not-Repetitive (TC =100 oC, Pulse Width Limited by TJ max, δ <1%) TBD A Ptot Power Dissipat ion at Tc = 25 oC57 W Tj Junct ion Operat ing Temperature -40 to 140 oC Tstg St orage Temperature -65 to 150 oC THERMAL DATA Rthj-ca se Thermal Resistance Junction-case Max 2.0 oC/W Rth j-a mb. Thermal Resistance Junction-ambient Max 70 oC/W CURRENT AND VOLTAGE CONVENTIONS - + 13V OSC COMP SOURCE DR AIN VD D VCOMP VOSC VDD VDS ICOMP IOSC IDD ID FC00020 CONNECTION DIAGRAMS (Top View) PENTAWATT HV PowerSO-10 VIPer20B / VIPer20BSP 2/17 |
|
|
