 2 / 2 page
background image
INCHANGE Semiconductor
isc Product Specification
isc Silicon NPN Power Transistor
MJ413
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNIT
VCEO(SUS)
Collector-Emitter Sustaining Voltage
IC= 100mA; IB= 0
325
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC= 0.5A; IB= 50mA
0.8
V
VBE(sat)
Base-Emitter Saturation Voltage
IC= 0.5A; IB= 50mA
1.25
V
ICEX
Collector Cutoff Current
VCE= 400V;VEB(off)=1.5V
VCE= 400V;VEB(off)=1.5V;TC=125℃
0.25
0.5
mA
IEBO
Emitter Cutoff current
VEB= 5V; IC= 0
5.0
mA
hFE-1
DC Current Gain
IC= 0.5A; VCE=5V
20
80
hFE-2
DC Current Gain
IC= 1A; VCE=5V
15
fT
Current-Gain—Bandwidth Product
IC= 0.2A; VCE=10V; f=1.0MHz
2.5
MHz
