Rev. 10.01.08_123

DPS50-M

1 of 2

Embedded Power for

Business-Critical Continuity

DPS50-M

60 Watts

Medical

Special Features

•Medicalsafetyapprovals

•CEMarkEMC&LVD

•UniversalACinput

•Fullyregulatedoutput

•Overloadandshortcircuit

protection

•Internalremotesensetothe

outputplug

•Constantvoltage

•Highefficiency

•HighMTBF

•IEC320ACreceptacle,3pin

(type C14)

•BuiltinEMIfilter

(CISPR22ClassB)

•LEDpowergoodindicator

•Inputpower<74watts

•ComplieswithEN61000-3-2

•MeetsEnergyStar

•WEEE&CeCiVcompliant

Total Power:

30-60Watts

Input Voltage:

90-264VAC

127-300VDC

# of Outputs:

Single

Electrical Specifications

Safety

Input

Inputrange

90-264VAC(widerange)

127-300VDC

Frequency

47-440Hz

Inrushcurrent

<60A@230VAC,coldstart@25C

Inputcurrent

<2.0Arms@115VAC;<1A@230VAC

Efficiency

80%@fullloadtypical,@115VAC

EMI/RFI

FCCPart15,SubpartBClassB&EN55022(CISPR22)ClassB

Safetyground

leakagecurrent

275µAmax.@50/60Hz,264VACinput

Output

MaximumPower(Po)

60W(DPS52,30W)

Hold-uptime

10ms.typicalatfullload@115VAC

Overvoltageprotection

20%-45%abovenominaloutputmaximum

Latchingtype,recycleACtoreset.

Overloadprotection

Outputshortcircuitprotectionautorecover

Overloadprotected@120-150%abovemaximumrating

Cable/connector

DCcablewith2.5mmcenterplug

DCplugcenter+v

DCplugouter-v

Operatingtemperature: 0°to+40°Cambient.Derateeachoutputas2.5%perdegreefrom

40°Cto60°C.-20°Cstartup

Storagetemperature:

-40°Cto+85°C

Electromagnetic

susceptibility:

DesignedtomeetEN61000-4,-2,-3,-4,-5,-6,-8,-11,level3

Humidity:

Operating;non-condensing10%to90%RH

Vibration:

Threeorthogonalaxes,3sweepsperaxeat1oct/min.2Gpeak8Hz

to500Hz,operational

MTBFdemonstrated:

>550,000hoursatfullloadand25°Cambientconditions

EnvironmentalSpecifications

UL

UL60601-1

CSA

CSA-C22.2no.601.1-M90

VDE

07501/EN60601-1(IEC601)

CE

EMC&LVD

RoHS
