Power Inductors - Shielded

ctparts.com

Manufacturer of Passive and Discrete Semiconductor Components

800-684-5322 Inside US

949-453-1811 Outside US

Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.

CT Magnetics reserves the right to make improvements or change specifications without notice

CENTRAL

03.06.07

SPECIFICATIONS

Parts are only available ±20% inductance tolerance only

L Test

*Irms

**Isat

DCR

Part

Inductance

Freq.

Typ.

Typ.

Max.

Number

(µH)

(KHz)

(A)

(A)

(m

Ω

Ω)

CTIHLP107F-R50M

0.50

100

32

40

0.8

CTIHLP107F Series

Not shown at actual size.

CHARACTERISTICS

Description: SMD (shielded) power inductor

Applications: High density DC/DC converters. POL converters.

High current VRM/VRD for notebooks, Servers, and desktop

CPUs. High speed chargers.

Operating Temperature: -55°C to +125°C

Inductance Tolerance: ±20%

Testing: Inductance is tested on an HP4285A at 100KHz, 0.5V

Packaging: Tape & Reel

Marking: Parts are marked with inductance code

Additional Information: Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PHYSICAL DIMENSIONS

RECOMMENDED LAND PATTERN

A

B

D

C

XXX

Marking: Inductance Code

4.0

9.5

3.5

Unit: mm

RoHS

Compliant

*Irms DC current (A) will cause an approximately

ΔT of 40°C.

**Isat DC current (A) will cause L0 to drop approximately 20%.

Size

A

B

C

D

Max.

Max.

Max.

Typ.

mm

10.3

11.5

7.0

3.0

inches

0.40

0.45

0.27

0.12
