09150-R datasheet(1/1 Pages) QUALTEK

Part #	09150-R

Description	PLASTIC FAN RETAINER

PDF	1 Pages

Scroll/Zoom	100%

Manufacturer	QUALTEK [Qualtek Electronics Corporation]

Direct Link	http://www.qualtekusa.com

Logo

1 / 1 page

36.4

0.9

B. ZHANG

10-28-03

JJH / 10-28-03

Qualtek Electronics Corp.

FAN-S DIVISION

Part Number:

09150-R

Description:

PLASTIC FAN RETAINER

Tolerance

+/-

(mm)

Dim

range

(mm)

0-5

5-16

16-64

64-250

250-1000

1000-1500

Drawn / Date

Checked / Date

Approved / Date

0.1

0.15

0.2

0.4

0.5

1.0

UNIT: mm

CONTROLLED

APPROVED

DATE

DESCRIPTION

REV.

REVISION

B

RoHS Compliancy

06-01-06

DP

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK

ELECTRONICS AND NOT TO BE REPRODUCED FOR OR

COMMUNICATED TO A THIRD PARTY WITHOUT THE

EXPRESS WRITTEN PERMISSION OF AN OFFICER OF

QUALTEK ELECTRONICS.

REV: B

Similar Part No. - 09150-R
