ADL5535ARKZ-R7 Datasheet(PDF) 3 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADL5535ARKZ-R7 Datasheet(HTML) 3 Page - Analog Devices |
|
|
3 / 16 page  ADL5535 Rev. 0 | Page 3 of 16 SPECIFICATIONS VCC = 5 V and TA = 25°C, unless otherwise noted. Table 1. Parameter Test Conditions/Comments Min Typ Max Unit OVERALL FUNCTION Frequency Range 20 1000 MHz FREQUENCY = 20 MHz Gain 16.7 dB Output 1 dB Compression Point (P1dB) 17.7 dBm Output Third-Order Intercept (OIP3) Δf = 1 MHz, output power (POUT) = 3 dBm per tone 41.5 dBm Second Harmonic POUT = 0 dBm −59.5 dBc Third Harmonic POUT = 0 dBm −93 dBc Noise Figure 3.0 dB FREQUENCY = 70 MHz Gain 16.5 dB vs. Frequency ±50 MHz ±0.33 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.16 dB vs. Supply Voltage 4.75 V to 5.25 V ±0.04 dB Output 1 dB Compression Point (P1dB) 18.9 dBm Output Third-Order Intercept (OIP3) Δf = 1 MHz, output power (POUT) = 3 dBm per tone 43.5 dBm Second Harmonic POUT = 0 dBm −64 dBc Third Harmonic POUT = 0 dBm −93 dBc Noise Figure 3.0 dB FREQUENCY = 190 MHz Gain 15.2 16.1 17.0 dB vs. Frequency ±50 MHz ±0.06 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.17 dB vs. Supply Voltage 4.75 V to 5.25 V ±0.04 dB Output 1 dB Compression Point (P1dB) 17.8 18.9 dBm Output Third-Order Intercept (OIP3) Δf = 1 MHz, output power (POUT) = 3 dBm per tone 45.5 dBm Second Harmonic POUT = 0 dBm −60.2 dBc Third Harmonic POUT = 0 dBm −84.3 dBc Noise Figure 3.2 dB FREQUENCY = 380 MHz Gain 15.0 15.8 16.5 dB vs. Frequency ±50 MHz ±0.08 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.17 dB vs. Supply Voltage 4.75 V to 5.25 V ±0.05 dB Output 1 dB Compression Point (P1dB) 17.8 18.9 dBm Output Third-Order Intercept (OIP3) Δf = 1 MHz, output power (POUT) = 3 dBm per tone 45.5 dBm Second Harmonic POUT = 0 dBm −61.9 dBc Third Harmonic POUT = 0 dBm −75 dBc Noise Figure 3.3 dB FREQUENCY = 748 MHz Gain 15.2 dB vs. Frequency ±50 MHz ±0.10 dB vs. Temperature −40°C ≤ TA ≤ +85°C ±0.20 dB vs. Supply Voltage 4.75 V to 5.25 V ±0.06 dB Output 1 dB Compression Point (P1dB) 18.9 dBm Output Third-Order Intercept (OIP3) Δf = 1 MHz, output power (POUT) = 3 dBm per tone 42.0 dBm Second Harmonic POUT = 0 dBm −52.6 dBc Third Harmonic POUT = 0 dBm −68 dBc Noise Figure 3.2 dB |
|
|
