75185
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
5 of 10
www.unisonic.com.tw
QW-R113-003,F
PARAMETER MEASUREMENT INFORMATION
DRIVER TEST CIRCUITS:
Figure 1. For VOH, VOL, IOS(H), IOS(L)
Figure 2. For IIH, IIL
DRIVER VOLTAGE WAVEFORMS:
Figure 3.
Note 1. The pulse generator has the following characteristics: tw=25
μs, PRR=20kHz, Zo=50Ω, tr=tf<50ns.
2. CL includes probe and jig capacitance.
