Semiconductor Group

1

11.96

Hyper ARGUS® LED

Hyper-Bright, 3 mm (T1), TS GaAIAs LED,

Non Diffused

LH K376

q

Note: If the diffuser screen is tinted, the spectral

transmission must be adjusted to the wavelength emitted

by the LED.

Besondere Merkmale

q

farbloses, klares Gehäuse

q

Doppel-Heterostruktur in GaAlAs Technologie,

transparentes Substrat

q

Kunststoffgehäuse mit spezieller Formgebung

q

bei Einsatz eines äußeren Reflektors zur Hintergrundbe-

leuchtung von Leuchtfeldern und LCD-Anzeigen geeignet.

q

zur Direkteinkopplung in Lichtleiterflächen geeignet

q

gleichmäßige Ausleuchtung einer Streuscheibe (Weiß-

druck) vor dem äußeren Reflektor

q

Lötspieße mit Aufsetzebene

q

gegurtet lieferbar

q

Störimpulsfest nach DIN 40839

q

Hinweis: Bei farbigen Streuscheiben muß die spektrale

Transmission an die von der LED emittierte Wellenlänge

angepaßt werden.

Features

q

colorless, clear package

q

double heterojunction in GaAIAs technology, transparent

substrate

q

plasic package with a special design

q

in connection with an additional, custom

built reflector suitable for backlighting of display panels

q

for optical coupling into light pipes

q

uniform illumination of a diffuser screen in front of the

custom built reflector

q

solder leads with stand-off

q

available taped on reel

q

load dump resistant acc. to DIN 40839
