2 / 4 page ![]() UT3414 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 4 www.unisonic.com.tw QW-R502-248.E ABSOLUTE MAXIMUM RATINGS (Ta = 25°C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 20 V Gate-Source Voltage VGSS ±8 V Continuous Drain Current ID 4.2 A Pulsed Drain Current IDM 15 A Power Dissipation PD 1.4 W Junction Temperature TJ +150 °C Storage Temperature TSTG -55 ~ +150 °C Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. Pulse width limited by TJ(MAX) THERMAL DATA PARAMETER SYMBOL MIN TYP MAX UNIT Junction to Ambient θJA 100 125 °C/W ELECTRICAL CHARACTERISTICS (TJ=25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS=0V, ID=250µA 20 V Drain-Source Leakage Current IDSS VDS=16V, VGS=0V 1 µA Gate-Source Leakage Current IGSS VDS=0V, VGS=±8V 100 nA ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS=VGS, ID=250µA 0.4 0.6 1 V On State Drain Current ID(ON) VDS=5V, VGS=4.5V 15 A VGS=4.5V, ID=4.2A 41 50 VGS=2.5V, ID=3.7A 52 63 Static Drain-Source On-Resistance RDS(ON) VGS=1.8V, ID=3.2A 67 87 mΩ DYNAMIC PARAMETERS Input Capacitance CISS 436 pF Output Capacitance COSS 66 pF Reverse Transfer Capacitance CRSS VDS=10V, VGS=0V, f=1.0MHz 44 pF SWITCHING PARAMETERS Turn ON Delay Time tD(ON) 5.5 ns Turn ON Rise Time tR 6.3 ns Turn OFF Delay Time tD(OFF) 40 ns Turn OFF Fall-Time tF VDS=10V, VGS=5V, RL=2.7Ω RG=6Ω 12.7 ns Total Gate Charge QG 6.2 nC Gate Source Charge QGS 1.6 nC Gate Drain Charge QGD VDS=10V, ID=4.2A, VGS=4.5V 0.5 nC SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Diode Forward Voltage VSD VGS=0V, IS=1A 0.76 1 V Maximum Body-Diode Continuous Current IS 2 A Body Diode Reverse Recovery Time tRR IF=4A, dI/dt=100A/μs 12.3 ns Body Diode Reverse Recovery Charge QRR IF=4A, dI/dt=100A/μs 3.5 nC |
|
|
