ADP2325
Data Sheet
Rev. 0 | Page 26 of 32
SOFT START TIME PROGRAMMING
The soft start feature allows the output voltage to ramp up in
a controlled manner, eliminating output voltage overshoot
during soft start and limiting inrush current. The soft start
time is set to 3 ms.
nF
5
.
17
V
6
.
0
ms
3
μA
5
.
3
V
6
.
0
=
×
=
×
=
SS
SS
SS
t
I
C
Choose a standard component value of CSS1 = CSS2 = 22 nF.
INPUT CAPACITOR SELECTION
A minimum 10 µF ceramic capacitor is required, placed near
the PVINx pin. In this application, one X5R ceramic capacitor of
10 µF and 25 V is recommended.
