© 2001 Fairchild Semiconductor Corporation

www.fairchildsemi.com

KA393 / KA2903 • Rev. 1.0.3

2

Absolute Maximum Ratings

Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be

operable above the recommended operating conditions and stressing the parts to these levels is not recommended.

In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability.

The absolute maximum ratings are stress ratings only.

Symbol

Parameter

Min.

Max.

Unit

Power Supply Voltage

±18

36

V

Differential Input Voltage

36

V

Input Voltage

-0.3

+36.0

V

Output Short Circuit to GND

Continuous

Power Dissipation,

8-DIP

1040

mW

8-SOIC

480

Operating Temperature

KA393 / KA393A

0

+70

°C

KA2903

-40

+85

Storage Temperature

-65

+150

°C

Thermal Resistance,

Junction-to-Ambient

8-DIP

120

°C/W

8-SOIC

260

ESD

Electrostatic Discharge

Capability

Human Body Model, JESD22-A114

1000

V

Charged Device Model, JESD22-C101

2000
