background image
4
Ai7152S
A1 PROs Co., Ltd.
Professional Promotion Process Profit
NO
SYMBOL
I/O
DESCRIPTION
31
VREF
IO
DAC Voltage reference input or output
32
COMP
O
DAC Compensation for the internal reference amplifier
33
VCC_DAC
P
AVDD for DAC
34
DAC1
O
DAC 1 out
35
GND_DAC
G
AGND for DAC
36
VCC_DAC
P
AVDD for DAC
37
DAC2
O
DAC 2 out
38
GND_DAC
G
AGND for DAC
39
VSS
G
Digital GND
40
CPU_MODE
I
External CPU mode
41
EXT_7
IO
Digital video out 7 / VD Out
42
EXT_6
IO
Digital video out 6 / FLD Out
43
EXT_5
IO
Digital video out 5 / HD Out
44
EXT_4
IO
Digital video out 4 / CSYNC Out
45
VDD33
P
3.3V Power
46
EXT_3
IO
Digital video out 3 / Day Out / EXTIO_3
47
EXT_2
IO
Digital video out 2 / IR In
48
EXT_1
IO
Digital video out 1 / MD Out
49
EXT_0
IO
Digital video out 0 / IR PWM Out / EXTIO_0
50
EXT_8
IO
Digital video clock out / IRIS PWM Out
51
VSS
G
Digital GND
52
VRI
I
External V sync input for Line Lock
53
VDD33
P
3.3V Power
54
V1
O
CCD Vertical driving pulse phase 1
55
V2
O
CCD Vertical driving pulse phase 2
56
V3
O
CCD Vertical driving pulse phase 3
57
V4
O
CCD Vertical driving pulse phase 4
58
SG1
O
CCD Read out pulse 1
59
SG2
O
CCD Read out pulse 2
60
SUB
O
CCD Shutter speed control pulse
