Crimped MIL Connector Sockets for Discrete Wires

XG5N/XG5N-U

Double Row Sockets - Crimp Terminal

■ XG5N / XG5N-U

Ordering Information

* Order the required number of reels (10,000 contacts).

Note: The pitch between the two polarity guides on Connectors with 50, 60, or 64 contacts is 22.86 mm.

(15.6)

(16.4)

(C)

(D)

14.4

6.10

2.54

B

A

2.54

6.10 7.90

2.54

B

A

2.54

Triangular mark

Polarity guide

XG5N-U (with Lock Levers Attached)

XG5N

No. of contacts

Dimension (mm)

ABCD

10

17.26

10.16

26.80

26.20

14

22.34

15.24

31.88

31.28

16

24.88

17.78

34.42

33.82

20

29.96

22.86

39.50

38.90

26

37.58

30.48

47.12

46.52

30

42.66

35.56

52.20

51.60

34

47.74

40.64

57.28

56.68

40

55.36

48.26

64.90

64.30

50

68.06

60.96

77.60

77.00

60

80.76

73.66

90.30

89.70

64

85.84

78.74

95.38

94.78

Appearance

Socket and Lock Set

Note: The Locks and Sockets

are provided separately.

Socket Housing

Lock Levers

Crimp Contacts, Type 1

Crimp Contacts, Type 2

No. of

contacts

No. of

polarity

guides

Model

Model

Model

Model

Model

10

0

XG5N-100-U

XG5N-100

XG5U-0001

XG5W-0231

(loose contacts)

XG5W-0231-R*

(reel contacts)

XG5W-0232

(loose contacts)

XG5W-0232-R*

(reel contacts)

1

XG5N-101-U

XG5N-101

14

1

XG5N-141-U

XG5N-141

16

1

XG5N-161-U

XG5N-161

20

1

XG5N-201-U

XG5N-201

26

1

XG5N-261-U

XG5N-261

30

1

XG5N-301-U

XG5N-301

34

1

XG5N-341-U

XG5N-341

40

1

XG5N-401-U

XG5N-401

50

1

XG5N-501-U

XG5N-501

2

XG5N-502-U

XG5N-502

60

1

XG5N-601-U

XG5N-601

2

XG5N-602-U

XG5N602

64

1

XG5N-641-U

XG5N-641

2

XG5N-642-U

XG5N-642
