background image
Si3226/7
Si3208/9
Preliminary Rev. 0.33
35
Table 19. 64-Pin TQFP Package Dimensions
Dimension
Min
Nom
Max
A—
—
1.20
A1
0.05
—
0.15
A2
0.95
1.00
1.05
b
0.17
0.22
0.27
c
0.09
—
0.20
D
12.00 BSC.
D1
10.00 BSC.
e
0.50 BSC.
E
12.00 BSC.
E1
10.00 BSC.
L
0.45
0.60
0.75
aaa
—
—
0.20
bbb
—
—
0.20
ccc
—
—
0.08
ddd
—
—
0.08
Q0
°
3.5
°
7
°
Notes:
1. All dimensions shown are in millimeters (mm) unless otherwise noted.
2. Dimensioning and tolerancing per ANSI Y14.5M-1994.
3. This package outline conforms to JEDEC MS-026, variant ACD.
4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020C
specification for small body components.
