background image
ADA4891-1/ADA4891-2
Rev. A | Page 10 of 20
140
150
160
170
180
190
200
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
OUTPUT STEP AMPLITUDE (V)
RISING EDGE
FALLING EDGE
VS = 5V
G = +2
RL = 150Ω
Figure 30. Slew Rate vs. Output Step
–1
0
1
2
3
5ns/DIV
1V/DIV
INPUT
VS = ±2.5V
G = +1
RL = 1kΩ
OUTPUT
Figure 31. Input Overdrive Recovery From Positive Rail
–3
OUTPUT
–2
–1
0
1
INPUT
VS = ±2.5V
G = +1
RL = 1kΩ
1V/DIV
5ns/DIV
Figure 32. Input Overdrive Recovery from Negative Rail
–3
–2
–1
0
1
2
3
INPUT
OUTPUT
VS = ±2.5V
G = –2
RL = 1kΩ
1V/DIV
5ns/DIV
Figure 33. Output Overdrive Recovery from Positive Rail
–3
–2
–1
0
1
2
3
VS = ±2.5V
G = –2
RL = 1kΩ
OUTPUT
INPUT
1V/DIV
5ns/DIV
Figure 34. Output Overdrive Recovery from Negative Rail
–
–80
–70
–60
–50
–40
–30
20
0.1
1
10
100
FREQUENCY (MHz)
VS = 5V
Figure 35. CMRR vs. Frequency
