AS3953

Datasheet - A pp l ic a t io n I n f or m a t i on

8.3.6 Definition of Number of Transmitted Bytes

Number of Transmitted Bytes Register 1.

Note:

Default setting is set at power-up and after

Set Default command.

Number of Transmitted Bytes Register 2.

Note:

Default setting is set at power-up and after

Set Default command.

Address# 10h : Number of Transmitted Bytes 1

Type: RW

Bit

Name

Default

Function

Comments

7RFU

Number of full bytes to be

transmitted in one command, MSB

bits

Maximum supported number of bytes is 1023

6RFU

RFU

ntx9

ntx8

ntx7

ntx6

ntx5

Address# 11h : Number of Transmitted Bytes 2

Type: RW

Bit

Name

Default

Function

Comments

ntx4

Number of full bytes to be transmitted

in one command, LSB bits

Maximum supported number of bytes is 1023

ntx3

ntx2

ntx1

ntx0

nbtx2

Number of bits in the split byte

000 means that all bytes all full

Applicable in

- Level-3 Protocol mode in case configuration

bit

txbs is set (bit stream Tx)

- Framing mode

nbtx1

nbtx0
