3 / 9 page

TS19702

High Power Factor Corrector LED Driver

3/9

Version: A12

Function Block

Pin Description

Pin No.

Name

Function

VCC

Power supply pin

GND

Ground pin

OUT

The output driver for driving the external MOSFET

DIM

Dimming control pin by input a DC voltage

COMP

Feedback compensation network

Current sense pin, connect to sense the MOSFET current
