SMD Power Inductors - CPUD Series
Electrical Characteristics
Part Number
Inductance
(
H)
Tolerance
(±%)
Test
Frequency
(KHz)
RDC
(mΩ) ±8%
Isat
(A) Max
Irms
(A) Max
Marking
CPUD0806MN-R60M-N
0.6
20
100
2.1
24
20
R60
CPUD0806MN-1R0M-N
1.0
20
100
3.0
15
18
1R0
CPUD0806MN-1R5M-N
1.5
20
100
4.5
11
13
1R5
CPUD0806MN-2R2M-N
2.2
20
100
4.5
8
13
2R2
CPUD0806MN-3R3M-N
3.3
20
100
6.8
7
11
3R3
CPUD0806MN-4R7M-N
4.7
20
100
12.0
5
7
4R7
CPUD1108IR-R30M-N
0.30
20
100
0.65
50
43
R30
CPUD1108IR-R56M-N
0.56
20
100
1.00
42
35
R56
CPUD1108IR-1R0M-N
1.0
20
100
2.00
50
28
1R0
CPUD1108IR-1R5M-N
1.5
20
100
3.65
30
20
1R5
CPUD1108IR-2R0M-N
2.0
20
100
5.20
27
15
2R0
CPUD1310IR-1R0M-N
1.0
20
100
1.15
42
32
1R0
CPUD1310IR-1R5M-N
1.5
20
100
1.85
42
26
1R5
CPUD1310IR-2R0M-N
2.0
20
100
3.50
35
21
2R0
CPUD1310IR-3R3M-N
3.3
20
100
5.00
22
17
3R3
CPUD1310IR-4R7M-N
4.7
20
100
8.60
17
12
4R7
 Isat for inductance drops 20% from its value without current
 Irms for a 40℃ rise above 25℃ ambient.
 Customized Specifications are available.
 Tested L: WK4237METER
RDC: HK502BC METER
Isat、Irms : WK3260B/ 3265B METER
