Characteristics

TMBAT49

2/6

Doc ID 3484 Rev 2

Characteristics

Table 1.

Absolute ratings (limiting values)

Symbol

Parameter

Value

Unit

VRRM

Repetitive peak reverse voltage

Forward continuous current

Tj = 70 °C

500

IFRM

Repetitive peak forward current

tp = 1 s

δ ≤ 0.5

IFSM

Surge non repetitive forward current

tp = 10 ms

Tstg

Storage temperature range

- 65 to +150

°C

Operating junction temperature range

- 65 to +125

°C

Maximum lead soldering temperature during 15 s

260

°C

Table 2.

Thermal parameter

Symbol

Parameter

Value

Unit

Rth(j-l)

Junction to lead

110

°C/W

Table 3.

Static electrical characteristics

Symbol

Parameter

Test conditions

Min.

Typ.

Max.

Unit

(1)

Pulse test: tp ≤ 300 µs, δ < 2%

Reverse leakage current Tj = 25 °C

VR = 80 V

200

µA

(1)

Forward voltage drop

Tj = 25 °C

IF = 10 mA

0.32

IF = 100 mA

0.42

IF = 1 A

Table 4.

Dynamic characteristics (Tj = 25 °C)

Symbol

Parameter

Test conditions

Min.

Typ.

Max.

Unit

Diode capacitance

F = 1 MHz

VR = 0 V

120

VR = 5 V
