Rev.4.00, Dec.18.2003, page 1 of 13

HD74ALVC2G53

2-channel Analog Multiplexer Demultiplexer

REJ03D0168–0400Z

(Previous ADE-205-636C (Z))

Rev.4.00

Dec.18.2003

Description

The HD74ALVC2G53 has 2-channel analog multiplexer / demultiplexer in an 8 pin package. Applications

include signal gating, chopping, modulation, or demodulation (modem), and signal multiplexing for analog

to digital and digital to analog conversion systems. Low voltage and high-speed operation is suitable for

the battery powered products (e.g., notebook computers), and the low power consumption extends the

battery life.

Features

• The basic gate function is lined up as Renesas uni logic series.

• Supplied on emboss taping for high-speed automatic mounting.

• Supply voltage range : 1.2 to 3.6 V

Operating temperature range:

−40 to +85°C

• All control input V

• Ordering Information

Part Name

Package Type

Package Code

Package

Abbreviation

Taping Abbreviation

(Quantity)

HD74ALVC2G53USE

SSOP-8 pin

TTP-8DBV

US

E (3,000 pcs/reel)
