02.10.2012

LED385-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mW/sr]

Min.

Typ.

Max.

LED385-01

±8°

24

Ø 5

1

LED385-02

±5°

24

Ø 5

2

LED385-03

±10°

20

Ø 5

3

LED385-04

±20°

12

Ø 5

4

LED385-05

±50°

4

Ø 5

5

LED385-06

±4°

22

Ø 5

6

LED385-09

±25° (long)

Ø 5

7

±10° (short)

Oval

LED385-46

Ø 5

8

LED385-41

±14°

Ø 4

9

LED385-42

±20°

Ø 4

10

LED385-31

Ø 3

11

LED385-33

±13°

14

Ø 3

12

LED385-34

Ø 3

13

LED385-36

±25°

7

Ø 3

14

* Radiant Power is measured by S3584-08

* Radiant Intensity is measured by Ando Optical Multi Meter AQ2140 & AQ2741

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
