21.11.2011

LED450-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mcd]

Min.

Typ.

Max.

LED450-01

±8°

2400

Ø 5

1

LED450-02

±5°

2500

Ø 5

2

LED450-03

±10°

2400

Ø 5

3

LED450-04

±20°

1000

Ø 5

4

LED450-05

±50°

150

Ø 5

5

LED450-06

±4°

4500

Ø 5

6

LED450-09

±25° (long)

1300

Ø 5

7

±10° (short)

Oval

LED450-46

Ø 5

8

LED450-41

±14°

Ø 4

9

LED450-42

±20°

Ø 4

10

LED450-31

Ø 3

11

LED450-33

±13°

1200

Ø 3

12

LED450-34

Ø 3

13

LED450-36

±25°

500

Ø 3

14

* Radiant Power is measured by S3584-08

* Brightness is measured by TekTronix J-16

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
