LED680-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mW/sr]

Typ.

LED680-01AU

±10°

25

Ø 5

1

LED680-02AU

±7°

25

Ø 5

2

LED680-03AU

±10°

25

Ø 5

3

LED680-04AU

±20°

10

Ø 5

4

LED680-05AU

±40°

2

Ø 5

5

LED680-06AU

±7°

25

Ø 5

6

LED680-09AU

±25° (long)

10

Ø 5

7

±15° (short)

Oval

LED680-46AU

Ø 5

8

LED680-41AU

±16°

20

Ø 4

9

LED680-42AU

±23°

10

Ø 4

10

LED680-31AU

Ø 3

11

LED680-33AU

±18°

10

Ø 3

12

LED680-34AU

Ø 3

13

LED680-36AU

±33°

4

Ø 3

14

* Radiant Power is measured by Photodyne #200

* Brightness is measured by TekTronix J-16

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
