PCHC412R8L Datasheet(PDF) 1 Page - Allied Components International |
|
|
|||||||||||||||||||||||||||||
PCHC412R8L Datasheet(HTML) 1 Page - Allied Components International |
|
|
1 / 1 page  SMD High Current Shielded Choke PCHC412R8L 15 ALLIED COMPONENTS INTERNATIONAL 949-356-1780 www.alliedcomponents.com RoHS 07/29/2015 Features • Magnetically shielded construction Electrical Inductance Range: 1.0uH additonal Tolerance: 20% over entire range Operating Temp: -55ºC ~ +125ºC Pre-Heat 150ºC, 1 minute. Test Equipment (L): WK 3260B • Ultra High saturation current up to 6.0A Resistance to Soldering Heat Solder Composition: Sn/Ag3.0/Cu0.5 Solder Temp: 260ºC ± 5ºC DCR: Chen HWA502 Irms: Test Frequency : 100KHz, 0.5Vdc • Low DC Resistance • Expanded operating temp range Immersion Time: 10 sec. ± 1 sec. .162+/-.008 (4.1+/-0.2) (4.6±0.2) .181±.008 (1.2) .047 (1.5±0.3) .06±.012 .04+/-.02 (1.0+/-0.5) no more than 30% from initial value without current. • Suitable for pick and place values available. Under no condition should the temperature of the part Physical Packaging: 2000 pieces per 13 inch reel. Marking: EIA Inductance Code IDC: 3260B WK & DC Bias 3265B WK All specifications subject to change without notice. Allied Part Number Inductance ( µH) Irms (A) Max(Typ) Test Frequency (KHz, 0.5V) Tolerance (±%) RDC(mΩ) PCHC412R8L-1R0M-RC Isat (A) 1.0 35(32) 20 100 6.0(6.5) 4.5(5.0) (Recommended Pattern) .098 (2.5) .059 (1.5) .146 (3.7) Max(Typ) Max(Typ) by 40ºC from Abmient without current. 0.0 0.2 0.4 0.6 0.8 1.0 1.2 0 1 23456 7 DC Current(A) 0 20 40 60 80 100 L(uH) △T(℃) Graph: The current at which the Temp will rise Isat: The current at which the inductance will drop by exceed 125ºC. *Photo for reference only. Dimensions: Inches (mm) MAX MAX |
