background image
JH22240320A
VER: 1.0
- 9 -
Issue date: 2013/08/15
JEWEL HILL ELECTRONIC CO.,LTD.
7.Pin Description
PIN
NO.
PIN OUT
FUNCTION DESCRIPTION
1
GND
Ground
2
IOVCC
Power Supply(1.8-2.8)
3
VCC
Power Supply
4
CS
Chip select input pin
5
/REST
System Reset Pin
6
RS
Data/Command Write Select pin
7
WR
Write execution control pin
8
RD
Read execution control pin
9
D0
Data Bus
10
D1
Data Bus
11
D2
Data Bus
12
D3
Data Bus
13
D4
Data Bus
14
D5
Data Bus
15
D6
Data Bus
16
D7
Data Bus
17
LED-A
LED Positive
18
LED-K1
LED Negative
19
LED-K2
LED Negative
20
LED-K3
LED Negative
21
GND
Ground
