JH30240400B
VER: 0.1
- 3 -
Issue date: 2013/08/01
JEWEL HILL ELECTRONIC CO.,LTD.
1. General Specification
Item
Display Panel
Remark
Display Format
240*RGBx400(H) Dots
Colour
262k colours
Pixel Pitch
0.054mmx0.162mm
Active Area
38.88mm(W)*64.8mm(H)
Outline Dimensions
45.04mm(W)*77.00mm(H)*2.0mm(T)
LCD Type
IPS
Polarizer Mode
Transmissive,Normally Black
View Angle(U/D/L/R)
80/80/80/80 DEG
Driver IC
S6D04D1
Backlight
LED
Backlight Color
White
Backlight Driver Type
External Power
