4.Electrical Specification

Main Window Display

(Unless specified, the ambient temperature Ta=25℃)

Properties

Sym.

Min

Typ.

Max

Unit

Note

Power for Circuit Driving

VDD

1.65

2.8

3.3

V

Note

Power for Circuit Logic

VCI

2.7

2.8

3.3

V

Note

BLU Driving Logic

Vbat

-

-

-

V

Low Voltage

VIL

0

-

0.2VDD

V

Logic Input

Voltage

High Voltage

VIH

0.8VDD

-

VDD

V

Low Voltage

VOL

0

-

0.1VDD

V

Logic Output

Voltage

High Voltage

VOH

0.9VDD

-

VDD

V

White

P

BBBBBBBBB

w

BBBBBBBBB

T.B.D

T.B.D

T.B.D

mW

Black

P

BBBBBBBBB

b

BBBBBBBBB

T.B.D

T.B.D

T.B.D

mW

Power

Consumption

Vertical Stripe

P

BBBBBBBBB

v

BBBBBBBBB

T.B.D

T.B.D

T.B.D

mW

Note:

The recommended operating conditions refer to a range in which operation of this

product is guaranteed. Should this range is exceeded, the operation cannot be

guaranteed even if the values may be without the absolute maximum ratings.

Accordingly, please make sure that the module is used within this range. And these

current values are measured under the condition that all devices are stopped, each

component is stable and logic signal is input.
