September 2003

1/15

®

STV9302A

Vertical Deflection Booster

for 2-APPTV/Monitor Applications with 70-V Flyback Generator

Main Features

s Power Amplifier

s Flyback Generator

s Output Current up to 2 App

s Thermal Protection

s Stand-by Control

Description

The STV9302A is a vertical deflection booster

designed for TV and monitor applications.

This device, supplied with up to 35 V, provides up to

2 App output current to drive the vertical deflection

yoke.

The internal flyback generator delivers flyback

voltages up to 70 V.

in double-supply applications, a stand-by state will

be reached by stopping the (+) supply alone.

HEPTAWATT

(Plastic Package)

ORDER CODE: STV9302A

7

6

5

4

3

2

1

Tab connected

Input (Non Inverting)

Output Stage Supply

Output

Ground Or Negative Supply

Flyback Generator

Supply Voltage

Input (Inverting)

to pin 4

1

Thermal

Protection

6

4

3

5

STV9302A

+

-

Power

Amplifier

7

2

Flyback

Generator

Inverting

Non-Inverting

Input

Ground or Negative Supply

Output

Flyback

Generator

Output Stage

Supply

Voltage

Supply
