FR3MB

FR3KB

FR3JB

FR3GB

FR3DB

FR3BB

FR3AB

FR3AB - FR3MB

Case: SMB(DO-214AA),Molded Plastic

Average Rectified Output Current

@ T

SURFACE MOUNT FAST RECOVERY RECTIFIER DIODES

Features

Glass Passivated Die Construction

Fast Recovery Time for High Efficiency

Low Forward Voltage Drop and High Current

Capability

Ideally Suited for Automatic Assembly

Plastic Material: UL Flammability

Classification Rating 94V-0

Mechanical Data

Terminals: Solder Plated Terminal -

Solderable per MIL-STD-202, Method 208

Polarity: Cathode Band or Cathode Notch

Marking: Type Number

Characteristic

Symbol

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

50

100

200

400

600

800

1000

V

RMS Reverse Voltage

35

70

140

280

420

560

700

V

°C

Non-Repetitive Peak Forward Surge Current

8.3ms Single half sine-wave Superimposed on Rated Load

(JEDEC Method)

100

A

Forward Voltage

1.3

V

Peak Reverse Current

°C

at Rated DC Blocking Voltage

@ TA = 125

°C

5.0

250

mA

Maximum Recovery Time (Note 3)

150

250

500

ns

Typical Junction Capacitance (Note 2)

50

pF

Typical Thermal Resistance Junction to Terminal (Note 1)

25

K/W

Operating and Storage Temperature Range

-65 to +150

°C

Notes:

2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.

3.0

A

CURRENT : 3.0 A

VOLT AGE RANGE: 50-1000V

Weight: 0.093 grams (approx.)

°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.

!

!

!

!

!

!

!

!

!

!

!

SMB(DO-214AA)

Dim

Min

Max

A

B

C

1.91

2.21

D

0.15

0.31

E

5.00

5.59

G

0.10

0.20

H

0.76

1.52

J

2.00

2.62

All Dimensions in mm

A

B

C

D

G

H

E

J

3.30

3.94

4.06

4.70

A

B

C

D

G

H

E

J

1 of 2

www.sunmate.tw
