INCHANGE Semiconductor
isc Product Specification
isc Website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc Silicon PNP Power Transistors
TIP30D
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
MAX
UNIT
VCEO(SUS)
Collector-Emitter Sustaining Voltage
IC= -30mA; IB= 0
-120
V
VCE(sat)
Collector-Emitter Saturation Voltage
IC= -1A; IB= -0.125A
-0.7
V
VBE(on)
Base-Emitter On Voltage
IC= -1A; VCE= -4V
-1.3
V
ICES
Collector Cutoff Current
VCE= -160V; VBE= 0
-0.2
mA
ICEO
Collector Cutoff Current
VCE= -120V; IB= 0
-0.3
mA
IEBO
Emitter Cutoff Current
VEB= -5V; IC= 0
-1.0
mA
hFE-1
DC Current Gain
IC= -0.2A; VCE= -4V
40
hFE-2
DC Current Gain
IC= -1A ; VCE= -4V
15
fT
Current-Gain—Bandwidth Product
IC= -0.2A; VCE= -10V
3
MHz
