Data Sheet

ADRF5040

Rev. A | Page 9 of 14

VDD = 3.3 V, VSS = −3.3 V, TCASE = 25°C, unless otherwise specified.

–20

–40

–60

–100

–80

–120

FREQUENCY (GHz)

RFC TO RF1

RFC TO RF2

RFC TO RF3

Figure 15. Isolation vs. Frequency, RFC to RF4 On

–5

–15

–25

–10

–20

–30

–35

–40

FREQUENCY (GHz)

RFC

Figure 16. Return Loss vs. Frequency, RFC to RF4 On

–20

–60

–100

–40

–80

–120

–140

FREQUENCY (GHz)

RF2 TO RF3

RF2 TO RF4

RF3 TO RF4

RF1 TO RF2

RF1 TO RF3

RF1 TO RF4

Figure 17. Channel to Channel Isolation vs. Frequency, RFC to RF1 On

–5

–15

–25

–10

–20

–30

–35

–45

–40

FREQUENCY (GHz)

CH1, CH2, CH3 AND CH4 (OFF)

CH1, CH2, CH3 AND CH4 (ON)

Figure 18. Return Loss vs. Frequency, RFC to RF4 On
