LED6000PHTR Datasheet(PDF) 47 Page - STMicroelectronics

Part # LED6000PHTR
Description  3 A, 61 V monolithic current source with dimming capability
PDF  49 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  STMICROELECTRONICS [STMicroelectronics]
Direct Link  http://www.st.com
Logo STMICROELECTRONICS - STMicroelectronics

LED6000PHTR Datasheet(HTML) 47 Page - STMicroelectronics

Back Button LED6000PHTR Datasheet HTML 41Page - STMicroelectronics LED6000PHTR Datasheet HTML 42Page - STMicroelectronics LED6000PHTR Datasheet HTML 43Page - STMicroelectronics LED6000PHTR Datasheet HTML 44Page - STMicroelectronics LED6000PHTR Datasheet HTML 45Page - STMicroelectronics LED6000PHTR Datasheet HTML 46Page - STMicroelectronics LED6000PHTR Datasheet HTML 47Page - STMicroelectronics LED6000PHTR Datasheet HTML 48Page - STMicroelectronics LED6000PHTR Datasheet HTML 49Page - STMicroelectronics
Zoom Inzoom in Zoom Outzoom out
 47 / 49 page
background image
DocID027777 Rev 2
47/49
LED6000
Package information
49
Table 10. HTSSOP16 package mechanical data
Symbol
Dimensions (mm)
Min.
Typ.
Max.
A
1.20
A1
0.15
A2
0.80
1.00
1.05
b
0.19
0.30
c
0.09
0.20
D
4.90
5.00
5.10
D1
2.80
3.00
3.20
E
6.20
6.40
6.60
E1
4.30
4.40
4.50
E2
2.80
3.00
3.20
e0.65
L
0.45
0.60
0.75
L1
1.00
k
0.00
8.00
aaa
0.10
