WSH315

Winson reserves the right to make changes to improve reliability or manufacturability.

©Winson, 2017/4/7

Page 2

Electrical Characteristics:

(T=+25˚C, Vdd=5.0V )

Characteristic

Symbol

Test Conditions

Min

Typ

Max

Units

Supply Voltage

Vcc

─

3.0

─

Supply Current

Isupply

B=0 Gauss

─

3.0

5.0

Quiescent Vout

V0G

B=0 G (Grade A)

2.45

2.5

2.55

B=0 G (Grade B)

2.35

2.5

2.65

Sensitivity

△Vout

B= 0 to ± 500 G

1.2

1.5

1.8

mV/G

Bandwidth

－

kHz

Measurable Guass

Range

MGR

Vdd=5V

－

±1500

－

Guass

Vdd=12V

－

±3000

－

Temperature Drift

△Vout

B=0 Gauss

－

±0.2

－

mV/℃

1. All output-voltage measurements are made with a voltmeter having an input impedance of at least 100kΩ

2. Do not apply any load on output pin, it will degrade IC’s performance.
