ST7LITE1

7/131

PIN DESCRIPTION (Cont’d)

Legend / Abbreviations for Table 1:

Type:

I = input, O = output, S = supply

In/Output level: CT= CMOS 0.3VDD/0.7VDD with input trigger

Output level:

HS = 20mA high sink (on N-buffer only)

Port and control configuration:

– Input:

float = floating, wpu = weak pull-up, int = interrupt, ana = analog

– Output:

OD = open drain, PP = push-pull

The RESET configuration of each pin is shown in bold which is valid as long as the device is in reset state.

Table 1. Device Pin Description

No.

Pin Name

Level

Port / Control

Main

Function

(after reset)

Alternate Function

Input

Output

1VSS

Ground

2VDD

Main power supply

RESET

I/O CT

Top priority non maskable interrupt (active low)

PB0/AIN0/SS

I/O

ei3

Port B0

ADC Analog Input 0 or SPI

Slave Select (active low)

Caution: No negative current

injection allowed on this pin. For

details, refer to section 13.2.2

on page 92

PB1/AIN1/SCK

I/O

Port B1

ADC Analog Input 1 or SPI Seri-

al Clock

Caution: No negative current

injection allowed on this pin. For

details, refer to section 13.2.2

on page 92

PB2/AIN2/MISO

I/O

Port B2

ADC Analog Input 2 or SPI Mas-

ter In/ Slave Out Data

PB3/AIN3/MOSI

I/O

ei2

Port B3

ADC Analog Input 3 or SPI Mas-

ter Out / Slave In Data

PB4/AIN4/CLKIN

I/O

Port B4

ADC Analog Input 4 or External

clock input

PB5/AIN5

I/O

Port B5

ADC Analog Input 5

PB6/AIN6

I/O

Port B6

ADC Analog Input 6

PA7

I/O CT HS

ei1

Port A7
