LIGHT EMITTING DIODES

1.6

÷÷4.6

M

6

4

6

6

W

•Light Emitting Diodes LED46 are designed for emitting at a spectral

range around 4600 nm. Heterostructures (HS) are grown on InAs

substrates. The output emission can be modulated by current flowing in

a forward direction.

•Light Emitting Diodes LED46 are developed for using in optical gas

sensors and medical diagnostics. They have stable output power and

lifetime more then 10000 hours.

•Related products: Our standard LED Driver provides power supply of

LED46 in two recommended here regimes (Quasi-CW and Pulsed).

Parameters

Min

Typ

Max

Wavelength,

µm

4.40

4.50

4.60

FWHM,

µm

1.00

1.10

1.20

Optical Power,

µW

Quasi-CW @ 200 mA

Pulsed@1A

4

100

6

120

8

140

Switching Time, ns

10

30

50

Operating Temperature

Range,

-240

÷+50

Emitting Area,

µm

300x300

Soldering temperature

260

Package

TO-18

LED46 - typical spectra at different temperatures

0,0

0,2

0,4

0,6

0,8

1,0

1,2

1,4

1,6

1,8

2,0

3000

3500

4000

4500

5000

Wavelength, nm

T=24 C

T=35 C

T=55 C

LED46 - typical Power

vs. current characteristic

0

2

4

6

8

0

50

100

150

200

Wavelength, nm

LED46 - typical Current -

Voltage characteristic

-30

-20

-10

0

10

20

30

40

-6

-4

-2

0

2

Voltage,V

Far field pattern

with and without reflector

0

0,1

0,2

0,3

0,4

0,5

0,6

0,7

0,8

0,9

1

LED46 (without reflector)

LED46-PR (with reflector)

Recommended regimes of operation

Quasi-CW

200 mA

250

µs

250

µs

1

µs

2 A

500

µs

f=2 kHz

f=2 kHz

Pulse
