Version 3.0/05.2017

Micro Crystal AG

Tel.

+41 32 655 82 82

Mühlestrasse 14

Fax

+41 32 655 82 83

CH-2540 Grenchen

sales@microcrystal.com

Switzerland

www.microcrystal.com

W

= Vdd 2.5V

V

= Vdd 3.3V

T

= ±50ppm

Blank = ±100ppm

A

= 0 to 70°C

B

= -40 to 85°C

C

= -55 to 125°C

X

= custom

Frequency

ENVIRONMENTAL

CHARACTERISTICS:

Storage temp. range

-65 to +125°C

Vibration resistance (survival)

10 to 2000Hz / 50g

Shocks resistance (survival)

5000g / 0.3ms / ½ sine

TERMINATIONS AND

PROCESSING:

Reflow soldering (peak)

+260°C / 10s max

Package

Ceramic 5 x 3.2 x 1.6mm

Lids

Ceramic

Terminations option T3 on request

with tinned Ag/Cu/Sn

E/D option 1 on request

Reaction time ˂ 1μs

Pin 1 open → Pin 3 Clock

H →

Clock

L →

Low

PRODUCT DESCRIPTION AND

ORDERING INFORMATION:

All specifications subject to change without notice.

Frequency «MHz»

40

80

100

128

Other frequencies on request

STANDARD FREQUENCIES:

- No power E/D function (pin 1) before Vdd is setting on

option 1 E/D

enable / disable

option 2

blank Au plated

T3 = tinned

customer

spec N°

E/D T3 XXX

Frequency

F= 40MHz

100MHz

130MHz

W

=Vdd = 2.5V

< 5mA

< 10mA

< 20mA

V

=Vdd = 3.3V

< 10mA

< 15mA

< 25mA

TAbLE 1: Idd

(Without load)

A unique part number will be generated for each product specification

20xxxx-EA00

xxx pcs

200xxx-ML00

xxx pcs
