HWI57A2 SERIES

•

Ideal for use in PV Inverters, String Inverters, Bidirectional Inverters

•

Flat wire coil minimizes losses at high frequency

•

Superior thermal management and significantly reduced size and

weight compared with conventional toroid designs

•

Operating Temperature -40ºC to +180ºC

•

Custom Design Available up to 500A current for inverter systems

20kW and up

ELECTRICAL PARAMETERS @ 25°C

Part Number

INDUCTANCE

(μH)

DCR

(mΩ)

SRF

(MHz)

Isat

(A) TYP

Irms

(A) TYP

±15%

MAX

TYP

10% Drop

20% Drop

30% Drop

20ºC Rise

40ºC Rise

HWI57A2-202A-130P

13.0

0.75

12

110

164

212

134

202

HWI57A2-162A-200P

20.0

1.15

9.0

88

130

190

106

162

HWI57A2-118A-390P

39.0

2.10

6.2

62

94

122

78

118

HWI57A2-108A-470P

47.0

2.60

5.4

56

86

112

70

108

HWI57A2-101A-510S

51.0

3.00

8

55

82

106

67

101

HWI57A2-085A-800S

80.0

4.50

5.3

44

66

86

56

85

HWI57A2-071A-121P

122.0

6.00

3.3

35

53

69

47

71

HWI57A2-059A-161S

157.0

8.40

4.3

31

47

61

39

59

HWI57A2-054A-191S

188.0

10.40

4.2

27

43

55

35

54

HWI57A2-041A-301S

300.0

17.40

3

23

34

44

27

41

HWI57A2-041A-321S

320.0

18.00

2.8

22

32.5

42.5

26.5

40.5

HWI57A2-040A-341S

342.0

18.60

3.3

21

31.5

41

26

40

HWI57A2-035A-491S

487.0

24.00

2.3

17.5

26.5

34.5

23.5

35.5

Note:

1.

Inductance measured at 10KHz, 1Vrms

2.

Isat is the DC current where the inductance drops the specified amount from its original value.

3.

Irms is the DC current that causes the specified temperature rise of the winding from 25°C ambient for the inductor without housing or potting. Aluminum case, thermal

conductive epoxy, or thermal pads can be added to improve cooling.

HIGH CURRENT INDUCTORS

FOR INVERTER SYSTEMS

Revised 07/21/2016

Product performance is limited to specified parameters. Data is subject to change without prior notice.
