2013/05/16

A.1

EM8564A

Absolute Maximum Ratings (Note1)

Supply Input Voltage, VCC ----------------------------------------------------------------------- 30V

D pin--------------------------------------------------------------------------------------------------- 650V

BNO, COMP, CS Pin --------------------------------------------------------------------------------- - 0.3V to 6.5V

Power Dissipation, PD @ TA = 25

℃

DIP 7 --------------------------------------------------------------------------------------------------- 1.5W

Package Thermal Resistance (Note2)

DIP 7 -------------------------------------------------------------------------------------------------- 80

℃/W

Junction Temperature ----------------------------------------------------------------------------- 150

℃

Lead Temperature (Soldering, 10 sec.) -------------------------------------------------------- 260

℃

Storage Temperature Range --------------------------------------------------------------------- -65

to 150

℃

ESD Susceptibility

(Note3)

HBM (Human Body Mode) ------------------------------------------------------------------------ 2KV

MM (Machine Mode) -------------------------------------------------------------------------------- 200V

Recommended Operating Conditions

(Note4)

Supply Input Voltage, VCC -----------------------------------------------------------------------

11V to 25V

VCC Capacitor ----------------------------------------------------------------------------------------

4.7uF to 47uF

Junction Temperature Range--------------------------------------------------------------------- -40

℃ to 125℃

Ambient Temperature Range--------------------------------------------------------------------

-40

℃ to 85℃
